Quick GP2 2000 Windlass Kit (Contactor Handle Switch Breaker) 800W 8mm
Quick GP2 2000 Windlass Kit (Contactor Handle Switch Breaker) 800W 8mm
Couldn't load pickup availability
Part No: Q-GP2151103K
A kit consisting of the Quick GP2 2000 horizontal on-deck windlass suitable for boats from 8-13 meters (26-43 ft), a 12V T6415-12 contactor unit, a windlass handle, windlass panel switch and a hydro magnetic circuit breaker 80A.
This GP2 2000 model of windlass has an anodized aluminium in hard oxide base and an epicyclical gearbox that provides much higher efficiency (+40% compared to equivalent traditional gearboxes).
The windlass features an 8mm gypsy which is suitable for 8mm DIN 766, 8mm ISO and 5/16" G4 chain, as well as 1/2" (12.7mm) rope. (PLEASE NOTE these values refer to a three-strand polyester rope with a rope/chain splice manufactured with the Quick system).
Product contents include the windlass (on deck unit and motor gearbox), contactor unit, base gasket, handle, windlass panel switch, hydro magnetic circuit breaker, bolts and screws (for assembly), drill template, user's manual and conditions of warranty.
Key Features
Horizontal on-deck windlass
Anodized alluminium in hard oxide base
Rope and chain on a single gypsy
Integrated sensor and magnet for chain counter
Supplied with pressure lever
IP66 watertight motor
Epicyclical gearbox
| Approvals | CE |
| Fuse | 80A Protection Circuit Breaker |
| Height Description | 135mm (5-5/16") |
| Series | Genius |
| Size | Motor Cable: 16mm2 (AWG 5) |
| Type | Horizontal Windlass |
| Voltage Description | 12V DC |
| Wattage | 800W |
| Weight | 10.2kg (22.4 lb) |
| Width | 217mm (7-31/32") |
| Brand | Quick |
| Primary Construction | Aluminium |
| Suitable For | Chain and Rope |
| Maximum Pull Load | 900kg (1984 lb) |
| Contents | Windlass, reversing contactor unit, switch, breaker, base gasket, drill template, handle, bolts and screws (for assembly), user’s manual and conditions of warranty. |
| Model | GP2 2000 |
| Thickness | Deck: 20mm - 40 mm (3/4” - 1” 9/16) |
| Boat Size | 8 to 13 metres in length |
| Gypsy Size | 8mm |
| Amps Description | 96A at 120kg |
| Depth | 249mm (9-25/32) |
